General Specification
Frame / Impeller: Plastic
Lead Wire: AWG#24 or Equivalent (+)Red, (-)Black
Ball Bearing 50,000Hrs(40°C)
Sleeve Bearing 30,000Hrs(40°C)
Operating temperature: -10°C~+70°C
Storage temperature: -40°C~+70°C
Art. No. | # | Rated | Operating | Input | Input | Speed | Max Air Volum | Max Static Pressure | Noise | Weight | ||
(CFM) | m3/min | Inch-H2O | mm-H2O | |||||||||
DC12038#12L | B.S | 12 | 7.0~13.8 | 0.26 | 3.12 | 2300 | 95 | 2.69 | 0.236 | 6 | 40 | 262 |
DC12038#12M | B.S | 12 | 7.0~13.8 | 0.46 | 5.52 | 2900 | 120.07 | 3.4 | 0.354 | 9 | 48 | 262 |
DC12038#12H | B.S | 12 | 7.0~13.8 | 0.6 | 7.2 | 3200 | 129.96 | 3.68 | 0.42 | 10.7 | 53 | 262 |
DC12038#12U | B.S | 12 | 7.0~13.8 | 1.05 | 12.6 | 3700 | 151.85 | 4.3 | 0.571 | 14.5 | 58 | 262 |
DC12038#24L | B.S | 24 | 14.0~27.6 | 0.19 | 4.56 | 2300 | 95 | 2.69 | 0.236 | 6 | 40 | 262 |
DC12038#24M | B.S | 24 | 14.0~27.6 | 0.3 | 7.2 | 2900 | 120.07 | 3.4 | 0.354 | 9 | 48 | 262 |
DC12038#24H | B.S | 24 | 14.0~27.6 | 0.38 | 9.12 | 3200 | 129.96 | 3.68 | 0.42 | 10.7 | 53 | 262 |
DC12038#24U | B.S | 24 | 14.0~27.6 | 0.5 | 12 | 3700 | 151.85 | 4.3 | 0.571 | 14.5 | 58 | 262 |
DC12038#48L | B.S | 48 | 28.0~56.0 | 0.08 | 3.84 | 2300 | 95 | 2.69 | 0.236 | 6 | 40 | 262 |
DC12038#48M | B.S | 48 | 28.0~56.0 | 0.15 | 7.2 | 2900 | 120.07 | 3.4 | 0.354 | 9 | 48 | 262 |
DC12038#48H | B.S | 48 | 28.0~56.0 | 0.18 | 8.64 | 3200 | 129.96 | 3.68 | 0.42 | 10.7 | 53 | 262 |
