General Specification
Frame / Impeller: Plastic
Lead Wire: AWG#24 or Equivalent (+)Red, (-)Black
Ball Bearing 50,000Hrs(40°C)
Sleeve Bearing 30,000Hrs(40°C)
Operating temperature: -10°C~+70°C
Storage temperature: -40°C~+70°C
Art. No. | # | Rated | Operating | Input | Input | Speed | Max Air Volum | Max Static Pressure | Noise | Weight | ||
(CFM) | m3/min | Inch-H2O | mm-H2O | |||||||||
DC9238#12L | B | 12 | 7.0~13.8 | 0.35 | 4.2 | 3200 | 71.69 | 2.03 | 0.298 | 7.58 | 49 | 245 |
DC9238#12M | B | 12 | 7.0~13.8 | 0.5 | 6 | 3800 | 85.46 | 2.42 | 0.406 | 10.3 | 52 | 245 |
DC9238#12H | B | 12 | 7.0~13.8 | 0.75 | 9 | 4400 | 100.29 | 2.84 | 0.572 | 14.53 | 55 | 245 |
DC9238#12U | B | 12 | 7.0~13.8 | 1 | 12 | 4800 | 111.18 | 3.12 | 0.655 | 16.9 | 63 | 245 |
DC9238#24L | B | 24 | 14.0~27.6 | 0.18 | 4.32 | 3200 | 71.69 | 2.03 | 0.298 | 7.58 | 49 | 245 |
DC9238#24M | B | 24 | 14.0~27.6 | 0.28 | 6.72 | 3800 | 85.46 | 2.42 | 0.406 | 10.3 | 52 | 245 |
DC9238#24H | B | 24 | 14.0~27.6 | 0.4 | 9.6 | 4400 | 100.29 | 2.84 | 0.572 | 14.53 | 55 | 245 |
DC9238#24U | B | 24 | 14.0~27.6 | 0.5 | 12 | 4800 | 111.18 | 3.12 | 0.665 | 16.9 | 63 | 245 |
DC9238#48L | B | 48 | 28.0~56.0 | 0.1 | 4.8 | 3200 | 71.69 | 2.03 | 0.298 | 7.58 | 49 | 245 |
DC9238#48M | B | 48 | 28.0~56.0 | 0.14 | 6.72 | 3800 | 85.46 | 2.42 | 0.406 | 10.3 | 52 | 245 |
DC9238#48H | B | 48 | 28.0~56.0 | 0.28 | 13.44 | 4400 | 100.29 | 2.84 | 0.572 | 14.53 | 55 | 245 |
DC9238#48U | B | 48 | 28.0~56.0 | 0.25 | 12 | 4800 | 111.18 | 3.12 | 0.665 | 16.9 | 63 | 245 |
