General Specification
Weight: 2800g
Impeller: PA66+25GF
Insulation Class: F
Motor Type: Ball Bearing
Control: 0-10VDC/PWM speed control
PWM Frequency: 1-10kHz
Operation Mode: S1
Operation Temperature: -30°C~+60°C
Motor Protection type: IP44
Protection: Polarity Protection, Soft Start, Locked-rotor protection, Over Current Protection, Over Voltage Protection
Cable Connection:
Red: 48VDC
Blue: GND
Yellow: 0-10VDC/PWM
White: tacho output (4 pulses/rev)
Specific Parameters
Art. No. | Bearing Type | Voltage (V) | Current (A) | Power (W) | Speed (RPM) | Noise (dBA) | Air Flow | Pressure (Pa) | |
M3/hr | CFM | ||||||||
NA250-48 | Ball | 48 | 2.8 | 135 | 2650 | 76 | 1513 | 890 | 589 |
