General Specification
Frame / Impeller: Plastic
Lead Wire: AWG#26 or Equivalent (+)Red, (-)Black
Ball Bearing 50,000Hrs(40°C)
Sleeve Bearing 30,000Hrs(40°C)
Operating temperature: -10°C~+70°C
Storage temperature: -40°C~+70°C
Art. No. | # Bearing Type | Rated Voltage (VDC) | Operating Voltage (VDC) | Input Current (A) | Speed (RPM) | Max Air Volum | Max Static Pressure | Noise (dB-A) | Weight (g) | ||
(CFM) | m3/min | Inch-H2O | mm-H2O | ||||||||
DC4010-12-1 | B.S | 12 | 7.0~13.8 | 0.072 | 5000 | 5.90 | 0.167 | 0.09 | 2.24 | 24.0 | 16.0 |
DC4010-24-1 | B.S | 24 | 14.0~27.6 | 0.04 | 5000 | 3.74 | 0.15 | 0.09 | 2.24 | 24.0 | 16.0 |
