General Specification
Frame / Impeller: Plastic
Lead Wire: AWG#20 or Equivalent (+)Red, (-)Black
Ball Bearing 50,000Hrs(40°C)
Sleeve Bearing 30,000Hrs(40°C)
Operating temperature: -10°C~+70°C
Storage temperature: -40°C~+70°C
Art. No. | # | Rated | Operating | Input | Input | Speed | Air Flow Air | Max Static Pressure | Noise | Weight | ||
(CFM) | m3/min | Inch-H2O | Pa | |||||||||
DC25489#24L | B | 24 | 14.0~27.6 | 1.5 | 36 | 1600 | 547.69 | 15.51 | 0.62 | 154.44 | 42 | 2140 |
DC25489#24M | B | 24 | 14.0~27.6 | 2.2 | 52.8 | 2100 | 718.85 | 20.36 | 0.82 | 204.25 | 55 | 2140 |
DC25489#24H | B | 24 | 14.0~27.6 | 3.5 | 84 | 2600 | 890 | 25.21 | 1.01 | 251.58 | 68 | 2140 |
DC25489#48L | B | 48 | 28.0~56.0 | 0.8 | 38.4 | 1600 | 547.69 | 15.51 | 0.62 | 154.44 | 42 | 2140 |
DC25489#48M | B | 48 | 28.0~56.0 | 1.2 | 57.6 | 2100 | 718.85 | 20.36 | 0.82 | 204.25 | 55 | 2140 |
DC25489#48H | B | 48 | 28.0~56.0 | 2 | 96 | 2600 | 890 | 25.21 | 1.01 | 251.58 | 68 | 2140 |
