General Specification
Frame / Impeller: Aluminum Alloy
Lead Wire: AWG#24 or Equivalent (+)Red, (-)Black
Ball Bearing 50,000Hrs(40°C)
Sleeve Bearing 30,000Hrs(40°C)
Operating temperature: -10°C~+70°C
Storage temperature: -40°C~+70°C
Art. No. | # | Rated | Operating | Input | Input | Speed | Max Air Volum | Max Static Pressure | Noise | Weight | ||
(CFM) | m3/min | Inch-H2O | mm-H2O | |||||||||
DC17050#12L | B | 12 | 7.0~13.8 | 0.79 | 9.48 | 1800 | 160 | 4.5 | 0.359 | 9.11 | 44 | 740 |
DC17050#12M | B | 12 | 7.0~13.8 | 1.35 | 16.2 | 2200 | 194.2 | 5.5 | 0.438 | 11.13 | 51 | 740 |
DC17050#24L | B | 24 | 14.0~27.6 | 0.56 | 13.44 | 2200 | 194.2 | 5.5 | 0.438 | 11.13 | 44 | 740 |
DC17050#24M | B | 24 | 14.0~27.6 | 0.97 | 23.28 | 2750 | 242.76 | 6.875 | 0.544 | 13.8 | 51 | 740 |
DC17050#24H | B | 24 | 14.0~27.6 | 2.3 | 55.2 | 3600 | 320 | 9 | 0.71 | 18.22 | 59 | 740 |
DC17050#48L | B | 48 | 28.0~56.0 | 0.4 | 19.2 | 2200 | 194.2 | 5.5 | 0.438 | 11.13 | 44 | 740 |
DC17050#48M | B | 48 | 28.0~56.0 | 0.5 | 24 | 2750 | 242.76 | 6.875 | 0.544 | 13.8 | 51 | 740 |
DC17050#48H | B | 48 | 28.0~56.0 | 0.6 | 28.8 | 3400 | 300.14 | 8.49 | 0.073 | 17.06 | 59 | 740 |
