General Specification
Frame / Impeller: Aluminum Alloy
Lead Wire: AWG#20 or Equivalent (+)Red, (-)Black
Ball Bearing 50,000Hrs(40°C)
Sleeve Bearing 30,000Hrs(40°C)
Operating temperature: -10°C~+70°C
Storage temperature: -40°C~+70°C
Art. No. | # | Rated | Operating | Input | Input | Speed | Max Air Volum | Max Static Pressure | Noise | Weight | ||
(CFM) | m3/min | Inch-H2O | mm-H2O | |||||||||
DC20060#12L | B | 12 | 7.0~13.8 | 2 | 24 | 2000 | 490 | 13.88 | 0.61 | 15.94 | 50 | 1031 |
DC20060#12M | B | 12 | 7.0~13.8 | 2.8 | 33.6 | 2500 | 532 | 15.07 | 0.74 | 18.79 | 58 | 1031 |
DC20060#12H | B | 12 | 7.0~13.8 | 3.5 | 42 | 3000 | 640 | 18.13 | 0.97 | 24.63 | 68 | 1031 |
DC20060#24L | B | 24 | 14.0~27.6 | 1 | 24 | 2000 | 490 | 13.88 | 0.61 | 15.94 | 50 | 1031 |
DC20060#24M | B | 24 | 14.0~27.6 | 1.5 | 36 | 2500 | 532 | 15.07 | 0.74 | 18.79 | 58 | 1031 |
DC20060#24H | B | 24 | 14.0~27.6 | 2.5 | 60 | 3000 | 640 | 18.13 | 0.97 | 24.63 | 68 | 1031 |
