General Specification
Frame / Impeller: Plastic
Lead Wire: AWG#24 or Equivalent (+)Red, (-)Black
Ball Bearing 50,000Hrs(40°C)
Sleeve Bearing 30,000Hrs(40°C)
Operating temperature: -10°C~+70°C
Storage temperature: -40°C~+70°C
Art. No. | # Bearing Type | Rated Voltage (VDC) | Operating Voltage (VDC) | Input Current (A) | Input Power (W) | Speed (RPM) | Max Air Volum | Max Static Pressure | Noise (dB-A) | Weight (g) | ||
(CFM) | m3/min | Inch-H2O | mm-H2O | |||||||||
DC6015#12D | B.S | 12 | 7.0~13.8 | 0.07 | 0.84 | 3000 | 11.55 | 0.327 | 0.087 | 2.21 | 23 | 52 |
DC6015#12L | B.S | 12 | 7.0~13.8 | 0.08 | 0.96 | 3500 | 13.45 | 0.381 | 0.12 | 3.01 | 25 | 52 |
DC6015#12M | B.S | 12 | 7.0~13.8 | 0.1 | 1.2 | 4000 | 15.36 | 0.435 | 0.16 | 3.93 | 28 | 52 |
DC6015#12H | B.S | 12 | 7.0~13.8 | 0.12 | 1.44 | 4500 | 17.3 | 0.49 | 0.2 | 4.97 | 31 | 52 |
DC6015#12U | B.S | 12 | 7.0~13.8 | 0.16 | 1.92 | 5000 | 19.42 | 0.55 | 0.24 | 6.1 | 34 | 52 |
DC6015#24L | B.S | 24 | 14.0~27.6 | 0.06 | 1.44 | 3500 | 13.45 | 0.381 | 0.12 | 3.01 | 25 | 52 |
DC6015#24M | B.S | 24 | 14.0~27.6 | 0.08 | 1.92 | 4000 | 15.36 | 0.435 | 0.16 | 3.93 | 28 | 52 |
DC6015#24H | B.S | 24 | 14.0~27.6 | 0.1 | 2.4 | 4500 | 17.3 | 0.49 | 0.2 | 4.97 | 31 | 52 |
DC6015#24U | B.S | 24 | 14.0~27.6 | 0.11 | 2.64 | 5000 | 19.42 | 0.55 | 0.24 | 6.1 | 34 | 52 |
